MAX Ecru 0001

Ref:

See technical data

Width 120 cm

MAX Ecru 0001

Ref:

See technical data

Other available colours

The range Max

ORCHESTRA MAX : the awning fabric with reinforced waterproofness and easy maintenance.

Orchestra MAX awning fabric is distinguished from Orchestra fabric by its colorless coating, which makes it completely waterproof. Ideal for fixed and permanent outdoor installations, such as awnings and pergolas, Orchestra MAX fabric guarantees a very high level of colorfastness, excellent protection from UV rays and weather exposure, as well as easy maintenance

Brochure

We also recommend

Orchestra Ecru 0001

From

€28.87 Excl. VAT/lm Public price

Explore

Order a sample

Orchestra Graphite 7132

From

€28.87 Excl. VAT/lm Public price

Explore

Order a sample

Orchestra Naturel 7133

From

€28.87 Excl. VAT/lm Public price

Explore

Order a sample

MAX Naturel 7133

From

€39.46 Excl. VAT/lm Public price

Explore

Order a sample

Sunworker Opaque White M005

From

€78.85 Excl. VAT/lm Public price

Explore

Order a sample

Awning braid Ecru 0000

From

€0.57 Excl. VAT/lm Public price

Explore

Spark Blanc U150

From

€49.29 Excl. VAT/lm Public price

Explore

Order a sample

Diklon 29 Ecru 0001

Explore

Order a sample

Free delivery

Select a format from the choices offered

Qty

Order a sample

Free delivery

Select a format from the choices offered

Qty

Calculate the thermal comfort of a Dickson awning fabric

Your glazing

The glazing’s U value

The glazing’s G value

Glazing D : Double reflective glazing, 4 + 16 + 4, low-emission layer on side 2 (interior side of exterior glass), Argon fill

Without solar protection, your glazing alone blocks 68% of solar energy.

Your glazing and an interior solar protection system block 75% of solar heat.

Your glazing and an exterior solar protection system block 89% of solar heat.

When fitted with this system, your thermal comfort is in Class 3

The NF EN 14501 standard indicates that when more than 35% of solar heat is transmitted, the protection level is low. But when it's between 15% and 10% or lower, the window + fabric combination becomes very efficient protection against heat inside a room.

These calculations were made according to the standard 14501.

Class	g_tot	Efficiency
0	1.00 ≥ g_tot ≥ 0.50	Very low efficiency
1	0.50 > g_tot ≥ 0.35	Low efficiency
2	0.35 > g_tot ≥ 0.15	Moderately efficient
3	0.15 > g_tot ≥ 0.10	Efficient
4	0.10 > g_tot ≥ 0.00	Very efficient

Note: The calculation assumes the fabric is placed parallel to glazing or at a maximum angle of 30° with glazing. This calculation remains a good estimate for a folding-arm awning.
